CATEGORY 6A UTP KEYSTONE JACK
UTP Cat.6A Keystone Jack 180 degree toolless, it's able to cut the wires easier and no need any extra punching down tool.
Much helpful for the easier and faster installation.
It's well match with Blank patch panels and Mounting boxes and faceplates.
Both Cat.5e & Cat.6 are available!
Various colors are option
Main Description:
The products are used in the equipment rooms & work area as communication connectors of the intelligent buildings
The structure of the Keystone Jack is compact, that can make your work more easy and fast. The original dust-free cap can prevent the cable from slipping off from the IDC ports
According to the standard of ISO/IEC 11801:2002 Class E & ANSI/TIA/EIA/568-B.2-1 CAT.6A standard
ETL Verified
According the regnirement of T568A & T568B. The T568A & T568B labels are sticked on the both sides of the product to give a exact guide when a engineer punches the cables
Connecting: RJ45 port for UTP patch cord and the IDC port for UTP horizontal cabling
In accordance with RoHS derective
Fitting for Cat.6A cabling systems, can also be used on Cat.6 and Cat.5e cabling systems Tooless fully, cut wires easlier without any extra crimping tool to save installation time as well as cost
Lifetime warranty
| Technique Characteristics: | |
| Housing and other plastic parts’ material: | PC UL94V-0 |
| 8 Pin of the RJ45 jack: | Phosphor bronze with golden plated 50U |
| Inserting duration: | 750 times |
| IDC Clips: | Tinned phosphor bronze pins. Fitting for 22AWG/23AWG/24AWG cables |
| Punching duration: | 250 times |
| Testing condition of transmitting capability: | 500MHz |
