CAT6A Shielded MIG+ HD Component Rated line is our premier line of data jacks. The MIG+ CAT6A Shielded Keystone Jacks are engineered with PCB technology, phosphor bronze IDC contacts, gold plated prongs, and a zinc die-cast with nickel plated housing. CAT6A Shielded MIG+ line of keystone jacks are also compatible with solid and stranded 23 AWG to 26 AWG size wires. The CAT6A Shielded MIG+ line of keystone jacks were engineered to simplify the termination helping you save time and money with features like easy to read wire labels, universal T568A & T568B wiring, 110 & Krone Punch down and tool-less termination when using the IDC cap.
Because we take great pride in our quality control procedures and our commitment to quality our CAT6A Shielded MIG+ HD Component Rated Keystone Jack line is subject to UL & ETL standards and is UL Listed & ETL Verified. Primus Cable's CAT6A Shielded MIG+ HD Component Rated Jacks meet all requirements for ANSI/EIA/TIA 568 C.2 Compliance and are inspected and tested to comply with stringent industry transmissions and safety standards.
|RJ45 Jack Housing:||Zinc Die-Casting With Nickel Plating|
|Contact Bracket:||PC, UL 94-V2, Transparent Color|
|RJ45 Contact Material:||Phosphor Bronze with Nickel Plating|
|Finish:||50 Micro-inch Gold Plated|
|CAP A&B:||Zinc Die-Casting With Nickel Plating|
|IDC Housing:||PC + Glass Fiber, Gray, UL 94V-2|
|Terminal:||Phosphor Bronze With Tin Plating|
|IDC Cap:||PC + Glass Fiber, UL94-HB,White Color|
|PCB:||FR4, UL 94V-0|
|Insertion Force:||30N Maximum|
|Retention Strength:||7.7 kgs Between Jack And Plug|
|Operation Temperature:||-10°C to 60°C|
|Life (Mating Cycles):||750 Cycles Minimum|
|IDC Wire Range:||Solid & Stranded 23-26 AWG Wire|
