CAT6A Shielded MIG+ HD Component Rated line is our premier line of data jacks. The MIG+ CAT6A Shielded Keystone Jacks are engineered with PCB technology, phosphor bronze IDC contacts, gold plated prongs, and a zinc die-cast with nickel plated housing. CAT6A Shielded MIG+ line of keystone jacks are also compatible with solid and stranded 23 AWG to 26 AWG size wires. The CAT6A Shielded MIG+ line of keystone jacks were engineered to simplify the termination helping you save time and money with features like easy to read wire labels, universal T568A & T568B wiring, 110 & Krone Punch down and tool-less termination when using the IDC cap.
Because we take great pride in our quality control procedures and our commitment to quality our CAT6A Shielded MIG+ HD Component Rated Keystone Jack line is subject to UL & ETL standards and is UL Listed & ETL Verified. Primus Cable's CAT6A Shielded MIG+ HD Component Rated Jacks meet all requirements for ANSI/EIA/TIA 568 C.2 Compliance and are inspected and tested to comply with stringent industry transmissions and safety standards.
Material Specs: | |
RJ45 Jack Housing: | Zinc Die-Casting With Nickel Plating |
Contact Bracket: | PC, UL 94-V2, Transparent Color |
RJ45 Contact Material: | Phosphor Bronze with Nickel Plating |
Finish: | 50 Micro-inch Gold Plated |
CAP A&B: | Zinc Die-Casting With Nickel Plating |
IDC Housing: | PC + Glass Fiber, Gray, UL 94V-2 |
Terminal: | Phosphor Bronze With Tin Plating |
IDC Cap: | PC + Glass Fiber, UL94-HB,White Color |
PCB: | FR4, UL 94V-0 |
Performance Specs: | |
Insertion Force: | 30N Maximum |
Retention Strength: | 7.7 kgs Between Jack And Plug |
Operation Temperature: | -10°C to 60°C |
Life (Mating Cycles): | 750 Cycles Minimum |
IDC Wire Range: | Solid & Stranded 23-26 AWG Wire |
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 3-5 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below
