| ITEM | FREQ UENCY | SPE CIFICATION |
| DC Current | 100mA MAX | |
| Total DC Resistance | 25Ω MAX | |
| POTS Impedance | 600Ω | |
| POTS Insert Loss | 1020Hz | -0.4dB MAX |
| POTS Insert Loss Distortion relative to 1020Hz | 300Hz - 3.4kHz 1 | dB MAX |
| POTS Return Loss | 300Hz - 500Hz | -14dB MIN |
| 500Hz - 2kHz | -18dB MIN | |
| 2kHz - 3.4kHz | -14dB MIN | |
| POTS Group Delay | 500Hz - 2.8kHz | 150μs MAX |
| xDSL Isolation | 30kHz - 138kHz | -55dB MIN |
| -45dB MIN | ||
| 138kHz - 1104kHz | -55dB MIN | |
| 1104kHz - 4.4MHz | -55dB MIN | |
| 4.4MHz - 12MHz | -55dB MIN ( VDSL ) | |
| Unbalance about earth | 50Hz - 600Hz | -40dB MIN |
| 600Hz - 3.4kHz | -46dB MIN | |
| 3.4kHz - 30kHz | -40dB MIN | |
| 30kHz - 1104kHz | -45dB MIN | |
| 1104kHz - 4.4MHz | -30dB MIN | |
| 4.4MHz - 30MHz | -30dB MIN |
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 3-5 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below
