Overview
Visible Fault Locator is the instrument used to identify and locate fiber failures by visible light in very sharp speed.
With strong penetrating laser, leakage points can be get clearly through 3mm PVC Jacket, Have high and stable power.
It is an ideal tool for failure identification in network installation and fiber devices and accessories manufactures.
Features and Benefits
1.CE & RoHs Certificate
2.Pulsed and CW operation
3.30 hours of operation (typical)
4.Battery Powered, Low Cost
5.Slim Pocket Size Rugged and nice outlook
Specification
Wavelength(nm) | 650±10nm, |
Output Power(mW) | 1mW / 5mW / 10mW / 20mW |
Modulation | 2Hz / CW |
Laser grade | CLASSⅢ |
Power supply | Two AAA battery |
Fiber Type | SM/MM |
Test interface | 2.5mm Universal Adapter(FC/SC/ST) |
Test distance | 1 Km~15 Km |
Housing material | Aluminum |
Product life (h) | >3000h |
Working temperature | -10℃~+50℃ |
Storage temperature | -20℃~+70℃ |
Net Weight(g) | 60g(without batteries) |
Humidity | <90% |
Size(mm) | φ14mm * L 161 mm |
