| Specifications | |
| Material | PBT or ABS(UL94V-0) |
| Contact | Phosphor Bronze |
| Silver Plating | 0.5 um.1.25 um.5 um |
| Mechanical Performance | |
| Insertion force | 40~75N |
| Pull Out Force | F≥25N(axial) F≥7.5N(radial) |
| IDC Life | 200 times(20-26 AWG Solid wire) minimum |
| Copper Conductor Diameter | OD:0.4~0.8(mm) |
| Environment Characteristic | |
| Storage Temperature | - 40 to 70° C |
| Operating Temperature | - 10 to 60° C |
| Relative Humidity | 95%, noncondensing |
| Electrical Performance | |
| Insulation resistance | 1000 Mohms minimum |
| Contact resistance | 7 mohms maximum |
| Dielectric intensity | AC 1000 Vrms 50Hz or 60Hz in 60s |
